We live in a changing world; change and management dominate all
aspects of modern industry and commerce. Although perhaps not immediately
apparent to some the management of the physical assets underpinning
today's industries has changed beyond recognition in under a generation.
These changes have occurred at all levels; from the obviously technical
shift as equipment and systems become increasingly complex, to strategic
transformation in the way we understand failure and the rationale
used to develop planned maintenance activities.
This paper looks at on the most significant strategic change to
impact the management of physical assets. This strategic change is
known as Reliability Centred Maintenance (RCM) and incorporates within
it several distinct shifts in the way we view physical assets and
their upkeep. RCM as a subject has been widely written about and it
is not the aim of this paper to provide a detailed account of the
process here. Rather, its aim is to provide an introduction to RCM
for new users and a quick history for the more experienced.
Evolution
Before looking at where we going, lets see where we have come from.
In the period up to and shortly after the First World War equipment
was generally simple and robust. The ways in which it could fail were
easily treated since the simplicity aided diagnostics and in some
cases equipment failure was an acceptable reason for loss of production.
In this environment, maintenance was largely reactive; simply to fix
things when they tailed, supplemented with simple tasks such as lubrication.
As an example, consider a steam train. The operating principle is
well understood, the systems are simple with a low level of automation
and low configurability (essentially doing one job), the construction
is robust & contains redundant elements and operational tolerances
are broad. There had to be a lot wrong before the train actually stopped
running.
However, during the Second World War, things began to change and
the availability of manpower declined in industrialized economies
of the time. Equipment became more complex, thus replacing the need
for manual intervention and reducing manpower requirements. Loss of
production through equipment failure also became unacceptable leading
to work on prevention of failures before they occurred. Conventional
wisdom suggests that as equipment gets older it "wears out" and becomes
more likely to fail. Using this model it was believed that failures
could be avoided if equipment was maintained before items "wore out"
and the failure occurred, i.e. planned intervention at the right time
would prevent failures, all that had to be determined was the right
time.
Interestingly, this line of thought yields an insight into the use
of the principal maintenance performance indicators to this day i.e.
the ratio of planned to breakdown maintenance. If the likelihood of
item failure increases with age, then planned intervention before
the failure should reduce the number of failures that occur. Using
this model suggests that if we continue to see failures then we have
not intervened early enough i.e. we do not yet know the right age.
Therefore it would seem appropriate to measure the effectiveness of
our strategy by measuring the amount of planned to unplanned maintenance.
This is widely reported in industry; improvement targets are even
established for this ratio (in most cases, the target is parity).
However, as will shortly be shown, this takes no account of the technical
characteristics of the failure and assumes that we want to prevent
all failures. This is not the case and the measurement is essentially
meaningless e.g. one German car plant has determined its most effective
ratio of planned to unplanned maintenance as 1:64!
The growth of civil aviation in late 1940's and 50?s triggered the
next step. At about the same time the Federal Aviation Administration
(FAA), the body responsible for regulating airlines in the USA was
worried about aircraft reliability. In an effort to reduce the number
of failures, the industry concluded that the maintenance was being
done too late based on the accepted "wear out" model of failure. So
the frequency of scheduled maintenance was increased. This lead to
higher maintenance costs which by the late 1950's prompted the industry
to look at the concept of preventive maintenance. In addition the
FAA was concerned that the reliability of some engines had not been
improved by changing either the type or frequency of overhaul. The
data available at the time indicated that although the frequency of
occurrence of some failures had been reduced, many more had remained
unchanged or actually increased! There was no way this finding could
be explained using the model of failure accepted at that time.
A task force, consisting of representatives from both the FAA and
the airlines, was established to investigate planned maintenance policies.
What evolved was a statement from the committee that the reliability
and the overhaul frequency of equipment was not necessarily directly
related and the common belief that reliability declined with increasing
age was not generally true. In fact;
1. Scheduled overhaul has little effect on the overall reliability
of a complex item unless there is a dominant failure mode.
2. There are many items for which there is no effective form of
scheduled maintenance.
It became obvious that too much emphasis had been placed on the
'right age? model.
The task force went on to develop a propulsion system reliability
program, each airline involved developed reliability programs for
their own particular areas of interest. These became the Handbook
for the Maintenance Evaluation and Program Development for the Boeing
747, more commonly known as MSG-1 (Maintenance Steering Group 1).
MSG-1 was subsequently improved and became MSG-2. In 1979 the Air
Transport Association (ATA) reviewed MSG-2 to incorporate further
developments in preventive maintenance, this resulted in MSG-3, the
Airline/Manufacturers Maintenance Program Planning Document.
United Airlines was sponsored by the US Department of Defense to
write a comprehensive document on the relationships between Maintenance,
Reliability and Safety. The report was prepared by Stanley Nowlan
and Howard Heap, it was called ?Reliability Centred Maintenance'.
Outside the aerospace industries, the application of MSG-3 is generally
known as RCM. The work of the airlines predated similar problems that
spread throughout industry during the 1980?s, consequently industry
has been fortunate in being able to use the airlines prior experience.
Why is RCM different?
The development of RCM has allowed us to literally re-define maintenance.
It re-focuses our thinking by differing in four very significant ways
from all that went before it:
1. The objective of a successful PM program is to prevent or mitigate
the consequences of failures, not to prevent the failures themselves.
Of the thousands of possible failure modes on any facility or installation,
each has a different effect on e.g. safety, operations, environment
or cost. It is the failure consequence that determines what, if any
resources will be used to prevent their occurrence. This leads to
the conclusion that that if the consequence of a failure does not
have an adverse effect on safety; operations, environment or cost,
then there is no need to carry out scheduled maintenance.
2. The consequences of failure differ depending on where and how
items are installed and operated. For example, missing an appointment
is a likely outcome of mechanical breakdown of a car usually driven
in urban areas, however the same failure in the middle of the Sahara
desert will have much more severe consequences. A formal review of
failure consequences focuses attention on maintenance tasks that have
most effect, and diverts energy away from those which have little
or no effect. This helps ensure that whatever is spent on maintenance
is spent where it will do the most good.
3. We no longer assume that all failures can be prevented by PM
or that even if they could be prevented, that it would desirable to
do so. Consider puncture of car tyres, what affects the number of
failures rate is the number of nails in the road, not the age of tyre.
PM is simply not applicable to this failure mode.
4. We are concerned principally with what we want the equipment
to do not what it actually is. Say we need a hand held, portable writing
instrument, capable of producing erasable text and lines in the width
range 0.2 to 0.5 mm. Both a wooden and a mechanical (propelling) pencil
broadly satisfy this simple description. The specification of what
we need is independent of the method used to achieve it. By identifying
what we actually want means we focus our maintenance on what matters
and identify any gaps in the required performance and that which a
system is capable of.
RCM builds on these simple ideas to determine applicable and effective
maintenance for each failure. The mechanics of the RCM process itself
are well described by other authors.
How does the RCM process fit into the Preventive Maintenance
cycle?
The power of RCM is not in doubt. There is more than enough hard
evidence from manufacturing, extractive, transport and process industries
that prove the techniques value in establishing and improving system
maintenance. It is however a sharp tool, and is usually best applied
in selected areas rather than broadly across a facility. To achieve
worthwhile results it must also be carried out by (or at least with)
the actual operators and maintainers of the systems in question. RCM
is not a "quick fix" solution, time and effort must be invested on
training, raising awareness, execution and implementation.
It does however achieve an understanding of how plant works, what
it can (or cannot) achieve, and the causes of failure. By doing so
it focuses maintenance effort on those areas where it is beneficial.
The analysis itself is carried out in groups consisting of experienced
supervisors, and specialists (if needed). These groups set up maintenance
tasks and an ownership concept is developed. The development of RCM
had lead to a radical change of direction in our understanding of
maintenance and its performance and has presented us with what were
entirely new concepts, Today, maintenance directly influences the
core aspects of modern business, safety and environmental integrity,
energy efficiency, quality, uptime and costs. RCM forms the core of
any effective maintenance policy and should therefore be at the heart
of your business.
